Perkins Gas Generators
Perkins Gas Engine Generating Set
Perkins Gas Engine Generating Set
- Designed for operation on a wide range of methane based gases (natural gas, biogas, marsh gas, coal mine methane gas, shale gas and biomass etc.).
- Individual large valve cylinder heads with matched deep bow.
- Pistons for greater swirl give exceptional mechanical efficiency and power-to-weight ratio.
- Reduced whole life cost through commonality of components with diesel engines. This reduces stocking levels and extends component life.
- Piston temperatures are controlled by an advanced gallery jet cooling system to give reliable power.
- Excellent service access for ease of maintenance.
- Specifications for natural gas and biogas are available, ensuring optimal engine performance for specific fuels
50HZ Cummins Natural Gas Generator Data Sheet (Made in UK & India)
| Model | Rated Power | Standby Power | Engine Model | Rotation Speed RPM(50HZ/60HZ) | Alternator Stamford /Leroy Somer | No.of Cylinders & Type | Overall dimension (L*W*H)(mm) | Weight(kg) | Click for Detail Data | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KW | KVA | KW | KVA | |||||||||
| P300NG | 306 | 383 | 337 | 421 | 4006-23TRS1 | 1500/1800 | Leroy Somer | 6.L | 4646*1992*2189 | 6056 |  |
|
| P375NG | 375 | 469 | 413 | 516 | 4006-23TRS2 | 1500/1800 | Leroy Somer | 6.L | 4646*1992*2189 | 6056 | |
|
| P425NG | 425 | 531 | 468 | 584 | 4008-30TRS1 | 1500/1800 | Leroy Somer | 8.L | 5540*1992*2283 | 7485 | |
|
| P500NG | 500 | 625 | 550 | 688 | 4008-30TRS2 | 1500/1800 | Leroy Somer | 8.L | 5540*1992*2283 | 7485 | |
|
| P600NG | 600 | 750 | 660 | 825 | 4012TESI | 1500/1800 | Leroy Somer | 12.Vee | 6000*2100*3000 | 10000 | |
|
| P875NG | 875 | 1094 | 963 | 1203 | 4016-61TRS1 | 1500/1800 | Leroy Somer | 16.Vee | 6430*2100*3370 | 13370 | |
|
| P1000NG | 1000 | 1250 | 1100 | 1375 | 4016-61TRS2 | 1500/1800 | Leroy Somer | 16.Vee | 6767*2100*2750 | 13000 | |
|
| Note: 1). Above Gensets are based on 50HZ/1500RPM and 60HZ/1800RPM. 2). Above Gensets are based on AC Voltage of 400/230V, Other special low AC Voltage and High Voltage of 6.3KV-10.5KV are available for your options. 3). Requirements for Special equipments such as Soundproof Canopy/Container, ATS, Synchronizing Parallel Control panels are available for your options. 4). Requirement for CHP System (Cogeneration/Heat Recovery System from exhuast gas or Hot Cylinder Water to generate hot water or steam) is available for your options. 5). The data herein can vary depending on individual production requirements or due to improved technology. |
||||||||||||
