Cummins Gas Generators
CUMMINS High-Performance Lean-Burn Natural Gas Fueled Generator Sets
Visa Energy Supplies the Cummins lean-burn gas fueled generator sets form the heart of our gas-powered solutions. Spanning power ratings of 315 kWe to 2 MWe and capable of running on natural gas and alternative gaseous fuels, the range delivers renowned Cummins reliability, extended maintenance intervals, high fuel efficiency and very low emissions, all from high density and compact power packages. This combination of durability, economy and environmental responsibility makes our lean-burn gas fueled generator sets the first choice for prime and standby power, high-hour peaking and cogeneration sites the world over, regardless of scale or location.
50HZ Cummins Natural Gas Generator Data Sheet (Made in UK & India)
| Genset Model | Continuous Power | Standby Power | Engine Model | Displacement (L) and Cylinder Type | Burn Technology | Electrical Efficiency(%) | Overall dimension (L*W*H)(mm) | Weight(kg) | Click for Detail Data | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KW | KVA | KW | KVA | |||||||||
| C315NFC* | 315 | 393 | / | / | QSK19 | 19(L6) | Lean Burn | 36.1 | 3500*1300*1800 | 4000 |  |
|
| C995N5C* | 995 | 1243 | / | / | QSK60G-HiE | 60(V16) | Lean Burn | 41.0 | 5120*2320*2770 | 14440 | |
|
| C1160N5C* | 1160 | 1450 | / | / | QSK60G | 60(16) | Lean Burn | 39.3 | 5000*2320*2970 | 13924 | |
|
| C1200N5C* | 1200 | 1500 | / | / | QSK60G | 60(16) | Lean Burn | 42.0 | 5120*2320*2770 | 15450 | |
|
| C1400N5C* | 1400 | 1750 | / | / | QSK60G-HiE | 60(16) | Lean Burn | 42.5 | 5120*2320*2770 | 15625 | |
|
| C1540N5C* | 1540 | 1925 | / | / | QSV91G | 91.6(18) | Lean Burn | 38.3 | 5603*1720*3136 | 17057 | |
|
| C1750N5C* | 1750 | 2187 | / | / | QSV91G | 91.6(18) | Lean Burn | 39.0 | 5921*1720*3136 | 19633 | |
|
| C2000N5C* | 2000 | 2500 | / | / | QSV91G | 91.6(18) | Lean Burn | 40.9 | 6065*2158*2772 | 20457 | |
|
| C2200N5C* | 2200 | 2750 | / | / | QSV91G | 91.6(18) | Lean Burn | 43.0 | 6065*2158*2790 | 20457 | |
|
| 60HZ Cummins Natural Gas Generator Data Sheet (Made in UK & India) | ||||||||||||
| C334N6C* | 334 | 417 | / | / | QSK19G | 19(L6) | Lean Burn | 36.1 | 3500*1300*1800 | 4000 | |
|
| C1000N6C* | 1000 | 1250 | / | / | QSK60G-HiE | 60(16) | Lean Burn | 43.0 | 5120*2320*2770 | 14440 | |
|
| C1100N6C* | 1100 | 1375 | / | / | QSK60G | 60(16) | Lean Burn | 43.0 | 5120*2320*2770 | 14440 | |
|
| C1250N6C* | 1250 | 1562 | / | / | QSK91G | 91.6(18) | Lean Burn | 37.9 | 5603*1720*3136 | 17057 | |
|
| C1400N6C* | 1400 | 1750 | / | / | QSK60G-HiE | 60(16) | Lean Burn | 41.8 | 5120*2320*2770 | 15625 | |
|
| C1540N6C* | 1540 | 1925 | / | / | QSV91G | 91.6(18) | Lean Burn | 38.3 | 5603*1720*3136 | 17057 | |
|
| C1750N6C* | 2000 | 2500 | / | / | QSV91G | 91.6(18) | Lean Burn | 40.9 | 6065*2158*2772 | 20457 | |
|
| C2000N6C* | 2200 | 2750 | / | / | QSV91G | 91.6(18) | Lean Burn | 43.0 | 6065*2158*2790 | 20477 | |
|
| Note: 1). Low voltage of 380V/400V/415V/440V/480V/690V and High Voltage of 6.3KV/6.6KV/11KV/13.8KV are avaible for option. 2). Above gensets can be coupled with Alternator of Leroy Somer or Stamford or Equal. 3). Special requirements for Soundproof Canopy/Container, ATS, Synchronizing Parallel panels and CHP are available for your options. 4). “*” means Cummins UK,”**” means Cummins India. Other models means assembled by Cummins OEM Partners. 5). Emission:”*” and “**” means NOx<500mg，other models comply USA EPA Standard. 6). Gas Fuel can be CNP, PNG, LNG, Biogas, Oil Associated Gas, Shale Gas, Coalmine Gas. 7). The data herein can vary depending on individual production requirements or due to improved technology. |
||||||||||||
VISA ENERGY ELECTRICITY GENERATING SETS SERIES POWERED BY MTU DIESEL ENGINES
Visa Energy Model G—TLE and G—TLS – Complete MTU Diesel Generating Set, 200kVA to 2500kVA Prime Power Rated, @ 125°C/45°C, Water Cooled Diesel Generating Set With Engine Mounted Radiator, 380/400 Volts, 50 Hz, 1500 Rpm coupled with either Stamford or Leroy Somer or Marathon Alternator, Insulation Class H, Skid Mounted on a Steel Base Frame with Operation Diesel Base Tank Supplied with Generator Mounted Deep Sea 7320 AMF Start/Stop Electrical Control Panel with Three (03) or Four (04) Pole Circuit Breaker, Battery , Battery Lead, Anti-Vibration Mounting, Exhaust Pipe and Silencer (Skid Mounted – Open Frame Type) or Installed Inside a 65 dBA at Seven (07) Metres Acoustic Sound Proofed Canopy as our customer wishes.
Visa Energy (60Hz) MTU Series Generating Set Technical Data
| Model | Frequency 60Hz | MTU Diesel Engine/th> | Dimension (L*W*H)(mm*mm*mm) | Detail Data | ||
|---|---|---|---|---|---|---|
| Standby(KVA/KW) | Prime(KVA/KW) | Open Type | Soundproof | |||
| M300TLY | 312/250 | 281/225 | 6R1600G10S 6R1600G70S* |
2600×1116×1960 | 3060×1140×2170 | |
| M375TLY | 375/300 | 350/280 | 6R1600G20S 6R1600G80S* |
3300×1200×2000 | 5000×1500×2300 | |
| M400TLY | 429/350 | 387/310 | 8V1600G10S 8V1600G70S* |
3300×1200×2000 | 5000×1500×2300 | |
| M500TLY | 500/400 | 450/360 | 8V1600G20S 8V1600G80S* |
3300×1200×2000 | 5000×1500×2300 | |
| M560TLY | 563/450 | 512/410 | 10V1600G10S 10V1600G70S* |
3500×1300×2100 | 5200×2000×2550 | |
| M625TLY | 625/500 | 562/450 | 10V1600G20S 10V1600G80S* |
3500×1300×2100 | 5200×2000×2550 | |
| M750TLY | 750/600 | 685/550 | 12V1600G20S 12V1600G80S* |
3700×1600×2200 | 5200×2000×2550 | |
| M900TLY | 875/700 | 830/664 | 12V2000G45 | 3700×1600×2200 | 5200×2000×2550 | |
| M1000TLY | 1000/800 | 937/750 | 12V2000G85 | 4000×1850×2300 | 6000×2050×2650 | |
| M1100TLY | 1125/900 | 1035/830 | 16V2000G45TB | 4000×1850×2300 | 6400×2050×2650 | |
| M1250TLY | 1250/1000 | 1137/910 | 16V2000G85TB | 5000×1950×2300 | 7000×2150×2650 | |
| M1500TLY | 1500/1200 | 1360/1090 | 18V2000G85 | 5300×2000×2400 | 40FT Container | |
| MTU HIGH POWERED DIESEL GENERATORS | ||||||
| M1600TLY | 1563/1250 | 1406/1125 | 12V4000G43 | 5600×2000×2400 | 40FT Container | |
| M1900TLY | 1850/1480 | 1630/1304 | 12V4000G43 | 5600×2000×2400 | 40FT Container | |
| M2200TLY | 2188/1750 | 1937/1550 | 12V4000G83 | 6000×2000×2700 | 40FT Container | |
| M2500TLY | 2500/2000 | 2250/1800 | 16V4000G43 | 6500×2000×2700 | 40FT Container | |
|
||||||
| *Standby rated power engines for standby rated gensets | ||||||
